UNV WIFI KIT 4CH NVR 1TB with 4x 2MP Mini Dome Cameras
UNV WIFI KIT 4CH NVR 1TB with 4x 2MP Mini Dome Cameras
$747.50
IN STOCK
- NVR301-04LB-W & 4x IPC322SR3-VSF28W-D
- 1TB storage
- ONVIF conformance
- Wireless setup
- SmartIR up to 30m
- IP67 cameras
Brand:
Uniview |
Code:
KTWF30104LB4T1TB
APN: 9319499078157 | Supplier Code:
APN: 9319499078157 | Supplier Code:
Accessories
NVR301-04LB-W
- Support 2.4GHz , Support two-antenna to strengthen the WiFi signal
- Embedded WiFi Module with high-performance and high stability
- Support CCMP encryption and WPA2-PSK authentication, Support IP cameras with WiFi in access
- Support Ultra 265/H.265/H.264 video formats
- 4-channel input
- Third-party IP cameras supported with ONVIF conformance: Profile S, Profile G, Profile T
- Support 1-ch HDMI, 1-ch VGA
- HDMI and VGA synchronous outputs provided
- Up to 1080p resolution recording
- 1 SATA HDD, Up to 10TB for each HDD
- ANR technology to enhance the storage reliability when the network is disconnected
- Support cloud upgrade
IPC322SR3-VSF28W-D
- Day/night functionality
- SmartIR, up to 30 m (98 ft) IR distance
- 2D/3D DNR (Digital Noise Reduction)
- Ultra 265,H.265, H.264, MJPEG
- Embedded smart algorithm
- Triple streams
- 9:16 corridor mode
- ONVIF Conformance
- Wide temperature range: -30°C to 60°C (-22°F to 140°F)
- Wide input voltage range of ±25%
- IP67
- IK10
| NVR301-04LB-W | |
| Video/Audio Input | |
| IP Video Input | 4-ch |
| Network | |
| Incoming Bandwidth | 40Mbps |
| Outgoing Bandwidth | 40Mbps |
| Remote Users | 128 |
| Protocols | P2P, UPnP, NTP, DHCP, PPPoE |
| Video/Audio Output | |
| HDMI/VGA Output | HDMI: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution | 1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Synchronous Playback | 4-ch |
| Corridor Mode Screen | 3/4 |
| Decoding | |
| Decoding format | Ultra 265/H.265/H.264 |
| Live view/ Playback | 1080p/960p/720p/D1/2CIF/CIF |
| Capability | 4 x 1080P@20, 4 x 720P@30 |
| Hard Disk | |
| SATA | 1 SATA interface |
| Capacity | Up to 10TB for each HDD |
| External Interface | |
| Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel：2 x USB2.0 |
| Wi-Fi | |
| Frequency | 2.4GHz |
| Transmission Rate | 150Mbps |
| Wireless Standards | IEEE 802.11b/g/n |
| Wireless Range | 160m(open environment) |
| General | |
| Power Supply | 12V DC Power Consumption: ≤ 9 W( without HDD ) |
| Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) |
| Dimensions(W×D×H) | 205mm ×228mm ×47mm (8.1" × 9.0"×1.9") |
| Weight ( without HDD ) | ≤ 0.98Kg(2.16lb) |
| IPC322SR3-VSF28W-D | |
| Sensor | 1/2.7", progressive scan , 2.0 megapixel, CMOS |
| Lens | 2.8 mm@F2.0 |
| DORI Distance | Lens: 2.8mm Detect(m): 45 Observe(m): 18 Recognize(m): 9 Identify(m): 4.5 |
| Angle of View (H) | 107.8° |
| Angle of View (V) | 56.7° |
| Angle of View (O) | 140.2° |
| Adjustment angle | Pan: 0°~360° Tilt: 0°~90° Rotate: 0°~360° |
| Shutter | Auto/Manual, 1/6~1/100000 s |
| Min. Illumination | Colour: 0.01 Lux (F2.2, AGC ON) 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| S/N | >52dB |
| IR Range | Up to 30m (98 ft) IR range |
| Defog | Digital Defog |
| WDR | DWDR |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Frame Rate | Main Stream:2MP (1920×1080): Max. 20 fps; Sub Stream: 2MP (1920×1080): Max. 20 fps; Third Stream:D1 (720×576): Max. 20 fps |
| 9:16 Corridor Mode | Supported |
| HLC | Supported |
| BLC | Supported |
| OSD | Up to 4 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Up to 8 areas |
| Motion Detection | Up to 4 areas |
| General Function | Watermark, IP Address Filtering, Tampering Alarm, Access Policy, ARP Protection, RTSP Authentication, User Authentication, |
| Edge Storage | Micro SD, up to 128 GB |
| Network Storage | ANR |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, |
| Compatible Integration | ONVIF(Profile S, Profile G), API |
| Wireless Standards | IEEE802.11b/g/n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | 20/40MHz Support |
| Modulation Mode | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmit Power | 802.11b: 17±1.5dBm @11Mbps 802.11g: 14±1.5dBm @ 54Mbps 802.11n: 12.5±1.5dBm |
| Receive Sensitivity | 802.11b: -90dBm @ 11Mbps (Typical) 802.11g: -75dBm @ 54Mpbs (Typical) 802.11n: -74dBm (Typical) |
| Transmission Rate | 802.11b: 11Mbps 802.11g: 54Mbps 802.11n: up to 150Mbps |
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| Power | 12 V DC(+/-25%) Power consumption: Max 5.5W |
| Dimensions (Ø x H) | Φ108.5 x 81 mm (Ø4.28” x 3.2”) |
| Weight | 0.45 kg (0.99 lb) |
| Working Environment | -30°C ~ +60°C (-22°F ~ 140°F), Humidity:10%~90% RH(non-condensing) |
| Ingress Protection | IP67 |
| Vandal Resistent | IK10 |
