UNV WIFI KIT 4CH NVR 1TB with 4x 2MP Mini Bullet Cameras
- NVR301-04LB-W & 4x IPC2122SR3-F40W-DD
- 1TB storage
- ONVIF conformance
- Wireless setup
- SmartIR up to 30m
- IP67 cameras
| NVR301-04LB-W | |
| Video/Audio Input | |
| IP Video Input | 4-ch |
| Network | |
| Incoming Bandwidth | 40Mbps |
| Outgoing Bandwidth | 40Mbps |
| Remote Users | 128 |
| Protocols | P2P, UPnP, NTP, DHCP, PPPoE |
| Video/Audio Output | |
| HDMI/VGA Output | HDMI: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution | 1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Synchronous Playback | 4-ch |
| Corridor Mode Screen | 3/4 |
| Decoding | |
| Decoding format | Ultra 265/H.265/H.264 |
| Live view/ Playback | 1080p/960p/720p/D1/2CIF/CIF |
| Capability | 4 x 1080P@20, 4 x 720P@30 |
| Hard Disk | |
| SATA | 1 SATA interface |
| Capacity | Up to 8TB for each HDD |
| External Interface | |
| Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel：2 x USB2.0 |
| Wi-Fi | |
| Frequency | 2.4GHz |
| Transmission Rate | 150Mbps |
| Wireless Standards | IEEE 802.11b/g/n |
| Wireless Range | 280m(open environment) |
| General | |
| Power Supply | 12V DC Power Consumption: ≤ 9 W( without HDD ) |
| Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) |
| Dimensions(W×D×H) | 205mm ×228mm ×47mm (8.1" × 9.0"×1.9") |
| Weight ( without HDD ) | ≤ 0.98Kg(2.16lb) |
| IPC2122SR3-F40W-D | |
| Sensor | 1/2.7", 2.0 megapixel, progressive scan, CMOS |
| Lens | [email protected] |
| DORI Distance | Lens: 4mm Detect(m): 60 Observe(m): 24 Recognize(m): 12 Identify(m): 6 |
| Angle of view(H) | 86.5° |
| Angle of View (V) | 44.1° |
| Angle of View (O) | 106.4° |
| Adjustment angle | Pan: 0°~360° Tilt: 0°~90° Rotate: 0°~360° |
| Shutter | Auto/Manual, 1/6~1/100000 s |
| Minimum Illumination | Colour: 0.01 Lux (F1.8 AGC ON) 0 Lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| S/N | >52dB |
| IR Range | Up to 30m (98 ft) IR range |
| Defog | Digital Defog |
| WDR | DWDR |
| Video | |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Frame Rate | Main Stream:2MP (1920×1080): Max. 20 fps; Sub Stream: 2MP (1920×1080): Max. 20 fps; Third Stream:D1 (720×576): Max. 20 fps |
| 9:16 Corridor Mode | Supported |
| HLC | Supported |
| BLC | Supported |
| OSD | Up to 4 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Up to 8 areas |
| Motion Detection | Up to 4 areas |
| Audio | |
| Audio Compression | G.711 |
| Suppression | Supported |
| Sampling Rate | 8 KHZ |
| General Function | Watermark, IP Address Filtering, Tampering Alarm, Access Policy, ARP Protection, RTSP Authentication, User Authentication, |
| Storage | |
| Edge Storage | Micro SD, up to 128 GB |
| Network Storage | ANR |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, |
| Compatible Integration | ONVIF(Profile S, Profile G), API |
| Wi-Fi | |
| Wireless Standards | IEEE802.11b/g/n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | 20/40MHz Support |
| Modulation Mode | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmit Power | 802.11b: 17±1.5dBm @11Mbps 802.11g: 14±1.5dBm @ 54Mbps 802.11n: 12.5±1.5dBm |
| Receive Sensitivity | 802.11b: -90dBm @ 11Mbps (Typical) 802.11g: -75dBm @ 54Mpbs (Typical) 802.11n: -74dBm (Typical) |
| Transmission Rate | 802.11b: 11Mbps 802.11g: 54Mbps 802.11n: up to 150Mbps |
| Interface | |
| Built-in Mic | Supported |
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| General | |
| Power | 12 V DC(+/-25%) Power consumption: Max 6.4 W |
| Dimensions (L × W × H) | 157.3 × 63 ×62.4 mm (6.2” × 2.5” × 2.5”) |
| Weight | 0.45 kg (0.99 lb) |
| Working Environment | -30°C ~ +55°C (-22°F ~ 131°F), Humidity ≤ 95% RH(non-condensing) |
| Ingress Protection | IP67 |
| Reset Button | Supported |
| Specifications | |
|---|---|
| UNV WIFI KIT 4CH NVR 1TB with 4x 2MP Mini Bullet Cameras - Specifications |
Brand: Uniview |
Code: KTWF30104LB4B1TB
MPN:
APN: 9319499078140 |
Supplier Code:
Brand: Uniview |
Code: KTWF30104LB4B1TB
MPN:
APN: 9319499078140 |
Supplier Code:
At a glance
- NVR301-04LB-W & 4x IPC2122SR3-F40W-DD
- 1TB storage
- ONVIF conformance
- Wireless setup
- SmartIR up to 30m
- IP67 cameras
