IPC3616SB-ADF28KM-I0 |
|||||
Camera |
|||||
Sensor |
1/2.7", 6.0 megapixel, progressive scan, CMOS |
||||
Min. Illumination |
Colour:0.0025lux (F1.6, AGC ON) 0 lux with IR |
||||
Day/Night |
IR-cut filter with auto switch (ICR) |
||||
Shutter |
Auto/Manual, 1 ~ 1/100000s |
||||
Adjustment angle |
Pan: 0°~360° |
Tilt: 0°~80° |
Rotate: 0°~360° |
||
WDR |
120dB |
||||
S/N |
>52dB |
||||
Lens |
|||||
Lens type |
|||||
Iris |
Fixed |
||||
Field of View (H) |
101.34° |
||||
Field of View (V) |
54.46° |
||||
Field of View (D) |
119.72° |
||||
DORI |
|||||
DORI Distance |
Lens (mm) |
Detect (m) |
Observe (m) |
Recognize (m) |
Identify (m) |
2.8 |
63(206.7ft) |
25.2(82.7ft) |
12.6(41.3ft) |
6.3(20.7ft) |
|
Illuminator |
|||||
IR Range |
Up to 30m (98.4 ft) IR range |
||||
Wavelength |
850nm |
||||
IR On/Off Control |
Auto/Manual |
||||
Video |
|||||
Video Compression |
Ultra 265, H.265, H.264, MJPEG |
||||
H.264 code profile |
Baseline profile, Main profile, High profile |
||||
Frame Rate |
Main Stream: 6MP (3072*2048),Max 25fps; 4MP(2560*1440) ,Max 30fps; 3MP(2304*1296), Max 30fps;1080P (1920*1080), Max 30fps;720P(1280*720), Max 30fps; Sub Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
||||
Video Bit Rate |
128 Kbps~16 Mbps |
||||
U-code |
Support |
||||
OSD |
Up to 8 OSDs |
||||
Privacy Mask |
Up to 4 areas per scene |
||||
ROI |
Up to 8 areas |
||||
Video stream |
Triple streams |
||||
Image |
|||||
White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
||||
Digital noise reduction |
2D/3D DNR |
||||
Smart IR |
Support |
||||
Flip |
Normal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise |
||||
Dewarping |
Support |
||||
HLC |
Support |
BLC |
Support |
Defog |
Digital Defog |
Intelligent |
|
Smart intrusion prevention |
Support false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection |
Recognition |
Face capture |
Statistical Analysis |
People counting, support people flow counting and crowd density monitoring |
Events |
|
Basic Detection |
Motion detection, Ultra motion detection, Audio detection, Tampering alarm |
General Function |
Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
Audio |
|
Audio Compression |
G.711U, G.711A |
Audio Bitrate |
64 Kbps |
Two-way Audio |
N/A |
Suppression |
Support |
Sampling Rate |
8KHz |
Storage |
|
Edge Storage |
Micro SD, up to 256 GB |
Network Storage |
ANR,NAS(NFS) |
Network |
|
Protocols |
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS,SSH |
Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API, SDK |
User/Host |
Up to 32 users. 2 user levels: administrator and common user |
Security |
Password protection, strong password, HTTPS encryption, Export operation logs, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
Client |
EZStation EZLive EZView |
Web Browser |
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above |
Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above |
|
Interface |
|
Audio I/O |
N/A |
Alarm I/O |
N/A |
Serial Port |
N/A |
Built-in Mic |
Support |
Built-in Speaker |
N/A |
WIFI |
N/A |
Network |
1 * RJ45 10M/100M Base-TX Ethernet |
Video Output |
N/A |
Certification |
|
EMC |
CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) |
Safety |
CE LVD (EN 62368-1:2014+A11:2017) CB (IEC 62368-1:2014) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) |
Environment |
CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
Protection |
IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) |
General |
|
Power |
DC 12V±25%, PoE (IEEE 802.3af) |
Power consumption: Max 5W |
|
Power Interface |
Ø 5.5mm coaxial power plug |
Dimensions (Ø x H) |
Φ111 x 95mm (Ø 4.4” x 3.7”) |
Weight |
0.45kg(0.99lb) |
Material |
Metal |
Working Environment |
-30℃~60℃(-22°F ~ 140°F),Humidity: ≤95% RH (non-condensing) |
Storage Environment |
-30℃~60℃(-22°F ~ 140°F),Humidity: ≤95% RH (non-condensing) |
Surge protection |
4KV |
Reset button |
N/A |
