Hardware

Sold in Pairs

Yes

Function Slots

LAN 2: 1 × RJ-45 10/100/1000 Mbps(PoE In);
LAN 1: 1 × RJ-45 10/100 Mbps(PoE Out)

Power Supply

PoE(802.3 af/at)

Power Consumption

< 30 W

Antenna

IPEX

Memory

DDR 128 MB

Indicator Light

1 × Power indicator;
2 × LAN port indicators;
1 × PoE indicator;
3 × Wireless signal strength indicators

External Port

2 × RJ–45;
1 × Reset

Performance

Wireless Standard

2.4 GHz: 802.11b/g/n;
5 GHz: 802.11a/n/ac

Recommended Video Channels

10-ch 4-MP IPC

Operating Frequency

2.4 GHz: 2.412 GHz–2.472 GHz;
5 GHz: 5.15 GHz–5.25 GHz; 5.735 GHz–5.835 GHz

Wireless Transmission Rate

2.4 GHz:300 Mbps;
5 GHz:867 Mbps

Channel Width

20/40/80 MHz

Max. Output Power

21 dBm + 12dBi

Antenna Direction Angle

Horizontal: 45°, vertical: 20°

Receiver Sensitivity

–96 dBm@11a_20M_6M

Polarization

Vertical/horizontal

Transmission Distance

3 km (9,842.52 ft)

Connected Wireless Terminals

8

PoE

PoE In: 802.3af/at(15W/30W);
PoE Out: 802.3af(15W)

Function

Operating Mode

Access point; Client

Equipment Management

Web management;
App management

Network Protocol

HTTPS;IPv4;UDP;NTP;DHCP;TCP

Encryption Mode

WPA-PSK/AES/TKIP

Security Mechanism

WPA/WPA2; hidden SSID

DHCP

Yes

Firmware Update

Web update;ConfigTool;App update

Software

Device Management: wireless bridge configuration on the app through WLAN; local web management; cloud management (cloud web and app); quick configuration guide; scanning code to add; Wi-Fi hotspot access cloud;
System Management: system log; factory settings; backup restore configuration; import configuration; DMZ; diagnosis and restart;
Network Management: DHCP/Static IP configuration; VLAN configuration; LLDP; topology display;
Wireless Network Management: 2.4 GHz Wi-Fi access management; working mode selection (access point/client); hide SSID (only access point); wireless output power adjustment; channel selection and channel width configuration; encryption mode configuration (non-encrypted and WPA2-PSK; wireless frame segmentation and aggregation

General

Operating Temperature

–30 °C to +65 °C (–22 °F to +149 °F)

Storage Temperature

–40 °C to +80 °C (–40 °F to +176 °F)

Operating Humidity

5%–95% (RH), non-condensing

Net Weight

0.74 kg (1.63 lb)

Gross Weight

2.095 kg (4.62 lb)

Product Dimensions

268 mm × 82 mm × 35 mm (10.55" × 3.23" × 1.38") (L × W × H)

Packaging Dimensions

312 mm × 205 mm × 136 mm (12.28" × 8.07" × 5.35") (L × W × H)

Protection

IP65

Statics Protection

Air discharge: 15 kV;
Contact discharge: 8 kV

Lightning Protection

Common mode: 6 kV;
Differential mode: 4 kV

Installation

Pole mount

Certifications

CE

Packing List

2 × Wireless bridge;
2 × Power cord;
2 × PoE adapter;
2 × Clamp(Φ59 mm to 82 mm);
2 × Antenna adjustment bracket;
2 × Mounting bracket;
1 × Quick start guide;
1 × Legal and regulatory information
