Protection |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Grade |
IP66 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Connection |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Connection |
M15 female connector |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Application |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Applicable Device |
DH-PFM364L-D1, DH-PFM363L-D1, and DH-PFM363LSD1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions |
Outer: 359.8 mm × 268.7mm × 116.0 mm(14.17" × 10.58" × 4.57") Inner: 282.0 mm × 209.0 mm × 98.5 mm (11.10" × 8.23" × 3.88") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Material |
Die casting aluminum |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Color |
Grey |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
8.5 kg (18.74 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
9.8 kg (21.61 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packaging Dimensions |
459 mm × 349 mm × 209 mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packaging Method |
1 pc in each carton |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature |
–20°C to 60°C (–4°F to 140°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity |
<95% (RH) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature |
0°C to 40°C (32°F to 104°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Humidity |
<95% (RH) |
Function |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Charging Current |
9A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Discharge Current |
9A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Rated Voltage |
DC12.8V |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Internal Resistance |
≤80mΩ |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Nominal Capacity |
45Ah |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Charging Voltage |
Max.DC14.6V |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max.Current |
Charging: 10A, Discharging: 10A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification |
CE: EN 61000-6-3, EN IEC 61000-6-1 FCC: FCC Part 15, Subpart B |
