Product Dimension

600.0 mm × 450.0 mm × 350.0 mm (23.62" × 17.72" × 13.78") (W × D × H)

Packaging Dimensions

685.0 mm × 535.0 mm × 435.0 mm (26.97" × 21.06" × 17.13") (W × D × H)

Effective Depth

300 mm (11.81")

Material

High-quality cold-rolled steel with vertical beams made of T1.2 mm and the remaining parts made of T0.8 mm.

Static Load Bearing

≤60 kg (132.28 lb)

Color

Black (RAL9004)

Installation Method

Wall mount; desktop mount

Panel Type

Default T4.0 mm right-hinged glass front door, rear panel for wall mount, and side door with detachable plastic clip.

Lock Type

Small round lock for the front door

Net Weight

10.0 kg (22.05 lb)

Gross Weight

12.0 kg (26.46 lb)

Environmental

Operating Temperature

–40 °C to +50 °C (–40 °F to +122 °F)

Operating Humidity

50%–90% (RH), non-condensing

Operating Altitude

<2,000 m (6,561.68 ft)

Protection

IP20

Accessory

Factory Accessories

Small round lock key × 2;
M6 × 12 Cam screw × 10;
M6 Cam nut × 10;
M6 Cam washer × 10;
User manual
