Leica Disto X3 Laser Distance Meter
- 150m measuring range
- Measuring accuracy of ± 1/16"
- Tilt accuracy of ± 0.2°
- 2m drop tested
- IP65 dust and water protection class
- Utilizes X-Range Power technology
- Speeds up stake-out the workflow
- Works perfectly with Leica DST 360
| Typ. distance measuring accuracy (ISO 16331-1 certified) | ± 1.0 mm |
| Range (ISO 16331-1 certified) | 0.05 up to 150 m |
| Measuring units | m, ft, in |
| X-Range Power Technology | Yes |
| Tilt sensor | Yes |
| Tilt sensor accuracy to the housing | ± 0.2° |
| Smart Base measuring range Horizontal Vertical |
 360° for use with Leica DST 360 |
| Typ. tolerance of P2P function for use with Leica DST 360 | ± 2mm at 2m, 5mm at 5m, 10mm at 10m |
| Levelling range | 5° for use with Leica DST 360 |
| Memory of last measurement | 20 |
| Free software for Windows | Yes |
| Free App for iOS and Android | Yes |
| Smart Room function support | Yes |
| General data interface | Bluetooth® Smart |
| Data interface for 3D point data | Bluetooth® Smart |
| Measurements per set of batteries | up to 4'000 (reduced when used with Bluetooth®) |
| Service life of batteries | up to 8h (reduced when used with Bluetooth®) |
| Multifunctional endpiece with automatic reference detection | Yes |
| Batteries | 2x AA Alkaline |
| Protection class | IP 65 |
| 2m drop tested | Yes |
| Dimensions | 132 x 56 x 29 mm |
| Weight with batteries | 184g |
| Art. No. | 850833 |
| EAN / UPC | 7640110697054 |
| Product Manuals | |
|---|---|
| Leica Disto X3 Laser Distance Meter - Product Manual |
- Leica Disto X3 Laser Distance Meter 850833
- Holster
- Hand Loop
- Batteries
- 3 Years Warranty
Brand: Leica Geosystems   |
  Code: LG850833

     MPN:




  APN: 7640110697047   |


  Supplier Code:

Brand: Leica Geosystems   |
  Code: LG850833

     MPN:




  APN: 7640110697047   |


  Supplier Code:

At a glance
- 150m measuring range
- Measuring accuracy of ± 1/16"
- Tilt accuracy of ± 0.2°
- 2m drop tested
- IP65 dust and water protection class
- Utilizes X-Range Power technology
- Speeds up stake-out the workflow
- Works perfectly with Leica DST 360
