UNV Mini PTZ Indoor 2MP 5x PoE

UNV Mini PTZ Indoor 2MP 5x PoE

  IN STOCK
PRODUCT ENQUIRY

• 1/2.9",progressive scan,CMOS
• 1920×1080 resolution,30fps
• 2.7~13.5mm,AF automatic focusing and motorized zoom lens
• Ultra 265,H.265, H.264, MJPEG
• Smart IR, up to 30m IR distance
• 2D/3D DNR, ROI
• DC12V, Wide voltage range of ±25%,PoE

Brand: Uniview   |    Code: IPC6412LR3-X5P
APN: 9319499092016   |    Supplier Code:

Optics

Day/night functionality

Smart IR , up to 30 m (98 ft) IR distance

Optical glass window with higher light transmittance

IR anti-reflection window to increase the infrared transmittance

2D/3D DNR (Digital Noise Reduction)

Compression

Ultra 265,H.265, H.264, MJPEG

Triple streams

ROI (Region of Interest)

Network

ONVIF Conformance

Structure

Support PoE power supply

Wide temperature range: -10°C to 50°C (14°F to 122°F)

Wide voltage range of ±25%

Sensor 1/2.9" progressive scan, 2.0 megapixel, CMOS
Lens 2.7~13.5mm,AF automatic focusing and motorized zoom lens
DORI Distance Lens Detect(m) Observe(m) Recognize(m) Identify(m)
2.7mm 43.4 17.4 8.7 4.3
13.5mm 217 86.8 43.4 21.7
Angle of View (H) 29.1°~104.3°
Angle of View (V) 16°~55.1°
Angle of View (O) 34.5°~142.9°
Shutter Auto/Manual, shutter time: 1 s ~ 1/100000 s
Minimum Illumination Colour: 0.03 lux (F1.2,AGC ON)
0 lux with IR
Iris F1.2
Day/Night IR-cut filter with auto switch (ICR)
Digital noise reduction 2D/3D DNR
S/N >52 dB
IR Range UP to 30m (98ft)
WDR DWDR
Video
Video Compression Ultra 265,H.265, H.264, MJPEG
H.264 code profile Baseline profile, Main Profile
Frame Rate Main Stream:1080P (1920×1080):Max. 30 fps;
Sub Stream:720P (1920×1080):Max. 30 fps;
Third Stream: CIF (352×288): Max. 30 fps
HLC Supported
BLC Supported
OSD Up to 4 OSDs
Privacy Mask Up to 4 areas
ROI Up to 2 areas
Motion Detection Up to 4 areas
Storage
Edge Storage Micro SD, up to 256 GB
Network Storage ANR
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL
Compatible Integration ONVIF(Profile S, Profile G), API
Pan & Tilt
Pan Range 0° ~ 350°
Pan Speed 0.1°/s ~ 60°/s
Preset speed: 60°/s
Tilt Range 0° ~ 90°
Tilt Speed 0.1° ~ 50°/s
Preset speed: 50°/s
Number of Presets 1024
Home Position Supported
Interface
Network 1 RJ45 10M/100M Base-TX Ethernet
Built-in Mic Supported
General
Power DC 12V±25%, PoE (IEEE802.3 af)
Power consumption: Max 12W
Dimensions (Ø x H) Φ129mm×143mm(Φ5.07” x5.63”)
Weight 0.75kg(1.65lb)
Working Environment –10°C ~ +50°C (14°F ~ 122°F), Humidity:≤95% RH(non-condensing)
Reset Button Supported
This product has yet to be reviewed

To be the first to review this product simply fill out the form to the left and let us know how you feel about this product!


To estimate the freight on this item simply enter the destination postcode and the desired quantity and click the "estimate" button.

FEATURES

Optics

Day/night functionality

Smart IR , up to 30 m (98 ft) IR distance

Optical glass window with higher light transmittance

IR anti-reflection window to increase the infrared transmittance

2D/3D DNR (Digital Noise Reduction)

Compression

Ultra 265,H.265, H.264, MJPEG

Triple streams

ROI (Region of Interest)

Network

ONVIF Conformance

Structure

Support PoE power supply

Wide temperature range: -10°C to 50°C (14°F to 122°F)

Wide voltage range of ±25%

SPECIFICATIONS

Sensor 1/2.9" progressive scan, 2.0 megapixel, CMOS
Lens 2.7~13.5mm,AF automatic focusing and motorized zoom lens
DORI Distance Lens Detect(m) Observe(m) Recognize(m) Identify(m)
2.7mm 43.4 17.4 8.7 4.3
13.5mm 217 86.8 43.4 21.7
Angle of View (H) 29.1°~104.3°
Angle of View (V) 16°~55.1°
Angle of View (O) 34.5°~142.9°
Shutter Auto/Manual, shutter time: 1 s ~ 1/100000 s
Minimum Illumination Colour: 0.03 lux (F1.2,AGC ON)
0 lux with IR
Iris F1.2
Day/Night IR-cut filter with auto switch (ICR)
Digital noise reduction 2D/3D DNR
S/N >52 dB
IR Range UP to 30m (98ft)
WDR DWDR
Video
Video Compression Ultra 265,H.265, H.264, MJPEG
H.264 code profile Baseline profile, Main Profile
Frame Rate Main Stream:1080P (1920×1080):Max. 30 fps;
Sub Stream:720P (1920×1080):Max. 30 fps;
Third Stream: CIF (352×288): Max. 30 fps
HLC Supported
BLC Supported
OSD Up to 4 OSDs
Privacy Mask Up to 4 areas
ROI Up to 2 areas
Motion Detection Up to 4 areas
Storage
Edge Storage Micro SD, up to 256 GB
Network Storage ANR
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL
Compatible Integration ONVIF(Profile S, Profile G), API
Pan & Tilt
Pan Range 0° ~ 350°
Pan Speed 0.1°/s ~ 60°/s
Preset speed: 60°/s
Tilt Range 0° ~ 90°
Tilt Speed 0.1° ~ 50°/s
Preset speed: 50°/s
Number of Presets 1024
Home Position Supported
Interface
Network 1 RJ45 10M/100M Base-TX Ethernet
Built-in Mic Supported
General
Power DC 12V±25%, PoE (IEEE802.3 af)
Power consumption: Max 12W
Dimensions (Ø x H) Φ129mm×143mm(Φ5.07” x5.63”)
Weight 0.75kg(1.65lb)
Working Environment –10°C ~ +50°C (14°F ~ 122°F), Humidity:≤95% RH(non-condensing)
Reset Button Supported
