UNV IP67 5MP IR 2.7-13.5mm Motorised Dome Camera NEW
5MP LightHunter Intelligent Vandal-resistant Dome Network Camera
• 1/2.7" progressive scan CMOS
• 2.7~13.5mm
• Smart IR, up to 50m IR distance
• 120dB True WDR
• Built-in Mic supports 2 way audio
• IP67 & IK10
Optics
1/2.7", Powered by lighthunter
Smart IR, up to 50m (164 ft) IR distance
Up to 120 dB Optical WDR (Wide Dynamic Range)
Compression
Ultra 265, H.265, H.264, MJPEG
Triple streams
2592*1944@20fps in the main stream
ROI (Region of Interest)
Network
ONVIF Conformance
Structure
Built-in Mic
DC12V or PoE power supply
Wide voltage range of ±25% in DC
Micro SD, up to 256 GB
Alarm 1 in and 1 out, Audio 1 in and 1 out
IP67 ingress protection
IK10 vandal resistant
Specifications
| UN-IPC3235SBADZKI0 | |||||
| Camera | |||||
| Sensor | 1/2.7", 5.0 megapixel, progressive scan, CMOS | ||||
| Lens | 2.7 ~ 13.5mm, AF automatic focusing and motorized zoom lens | ||||
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identify (m) |
| 2.7 | 60.8 | 24.3 | 12.2 | 6.1 | |
| 13.5 | 303.8 | 121.5 | 60.8 | 30.4 | |
| Angle of View (H) | 106.25° ~ 30.42° | ||||
| Angle of View (V) | 56.36° ~ 17.22° | ||||
| Angle of View (O) | 110.34° ~34.18° | ||||
| Adjustment angle | Pan: 0° ~ 355° | Tilt: 0° ~ 80° | Rotate: 0° ~ 355° | ||
| Shutter | Auto/Manual, 1 ~ 1/100000s | ||||
| Minimum Illumination | Colour:0.002 Lux (F1.35, AGC ON) 0Lux with IR |
||||
| Day/Night | IR-cut filter with auto switch (ICR) | ||||
| Digital noise reduction | 2D/3D DNR | ||||
| S/N | >56dB | ||||
| IR Range | Up to 40m (131ft) IR range | ||||
| Wavelength | 850nm | ||||
| IR On/Off Control | Auto/Manual | ||||
| Defog | Digital Defog | ||||
| WDR | 120dB | ||||
| Video | |||||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | ||||
| H.264 code profile | Baseline profile, Main Profile | ||||
| Frame Rate | Main Stream:5MP (2880*1620), Max 25fps; 4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 25fps; 1080P (1920*1080), Max 30fps; Sub Stream: D1 (720*576), Max 30fps; Third Stream: CIF (352*288), Max 30fps |
||||
| Video Bit Rate | 128 Kbps~16 Mbps | ||||
| OSD | Up to 8 OSDs | ||||
| Privacy Mask | Up to 4 areas | ||||
| ROI | Up to 8 areas | ||||
| Motion Detection | Up to 4 areas |
| Datasheets | |
|---|---|
| UNV IP67 5MP IR 2.7-13.5mm Motorised Dome Camera NEW - Datasheet |
Brand: Uniview |
Code: IPC3235SB-ADZKI0
MPN:
APN: 6937096302340 |
Supplier Code:
Brand: Uniview |
Code: IPC3235SB-ADZKI0
MPN:
APN: 6937096302340 |
Supplier Code:
At a glance
5MP LightHunter Intelligent Vandal-resistant Dome Network Camera
• 1/2.7" progressive scan CMOS
• 2.7~13.5mm
• Smart IR, up to 50m IR distance
• 120dB True WDR
• Built-in Mic supports 2 way audio
• IP67 & IK10
