UNV 2MP IP67 Starlight 5X 60FPS IR Bullet Camera
- 2MP 2.7~13.5mm f/1.2 motorized lens camera
- 58.4°~14.9° angle of view
- Smart IR up to 50m
- True 120dB WDR
- 60fps
- MicroSD slot up to 128GB
| Camera | |
| Sensor | 1/2.8", progressive scan,2.0megapixel, CMOS |
| Lens | 2.7~13.5mm，AF automatic focusing and motorized zoom lens |
| DORI Distance | Lens: 2.7mm ~ 13.5mm Detect（m): 41.9 ~ 209.5 Observe（m）: 16.7 ~ 83.8 Recognize（m）: 8.4 ~ 41.9 Identify（m）: 4.2 ~ 20.9 |
| Angle of View(H) | 121.36°~33.51 |
| Angle of View (V) | 58.4°~14.9° |
| Angle of View (O) | 139.9°~33.4° |
| Adjustment angle | Pan: 0°~360° Tilt: 0°~90° Rotate: 0°~360° |
| Shutter | Auto/Manual, shutter time: 1~1/100000 s |
| Minimum Illumination | Colour: 0.001Lux (F1.2, AGC ON) 0 Lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| S/N | >52 dB |
| IR Range | Up to 50m (164 ft) IR range |
| Defog | Digital Defog |
| WDR | 120dB |
| Video | |
| Video Compression | Ultra 265,H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Frame Rate | Main Stream:2MP (1920×1080): Max. 60fps; Sub Stream:720P (1280×720): Max. 30 fps; Third Stream:D1 (720×576): Max. 30fps; |
| 9:16 Corridor Mode | Supported |
| HLC | Supported |
| BLC | Supported |
| Privacy Mask | Up to 8 areas |
| ROI | Up to 8 areas |
| Motion Detection | Up to 4 areas |
| Smart | |
| Behavior Detection | Intrusion, cross line, motion detection |
| Intrusion | Enter and loiter in a pre-defined virtual region |
| Cross line | Cross a pre-defined virtual line |
| Motion detection | Moving within a pre-defined virtual region |
| Recognition | Face detection |
| Intelligent Identification | Defocus, Scene Change, Object Left, Object Moving |
| Statistical Analysis | People counting |
| General Function | Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio | |
| Audio Compression | G.711 |
| Two-way audio | Supported |
| Suppression | Supported |
| Sampling Rate | 8 KHZ |
| Storage | |
| Edge Storage | Micro SD, up to 128 GB |
| Network Storage | ANR |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP |
| Compatible Integration | ONVIF(Profile S, Profile G), API |
| Interface | |
| Audio I/O | Input: impedance 35 kΩ; amplitude 1 V [p-p] Output: impedance 600 Ω; amplitude 1 V [p-p] |
| Alarm I/O | 1/ 1 |
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| Video Output | 1 BNC, impedance 75 Ω; amplitude 1 V [p-p] |
| General | |
| Power | 12 V DC±25%, PoE (IEEE802.3 af) Power consumption: Max 10W |
| Dimensions (L × W × H) | 253.4 ×86×71.7 mm (9.98” × 3.4” × 2.8”) |
| Weight | 1.0kg |
| Working Environment | -35°C ~ +60°C (-31°F ~ 140°F), Humidity :10%~ 90% RH(non-condensing) |
| Ingress Protection | IP67 |
| Vandal Resistant | IK10 |
| Datasheets | |
|---|---|
| UNV 2MP IP67 Starlight 5X 60FPS IR Bullet Camera - Datasheet | Product Manuals |
| UNV 2MP IP67 Starlight 5X 60FPS IR Bullet Camera - Product Manual |
Brand: Uniview |
Code: IPC2322EBR5HDUPZ
MPN:
APN: 9319499062859 |
Supplier Code:
Brand: Uniview |
Code: IPC2322EBR5HDUPZ
MPN:
APN: 9319499062859 |
Supplier Code:
At a glance
- 2MP 2.7~13.5mm f/1.2 motorized lens camera
- 58.4°~14.9° angle of view
- Smart IR up to 50m
- True 120dB WDR
- 60fps
- MicroSD slot up to 128GB
Optics
- Starlight illumination
- 60fps Frame Rate
- Day/night functionality
- Smart IR, up to 50m (164 ft) IR distance
- Up to 120 dB Optical WDR(Wide Dynamic Range)
- 120dB TRUE WDR
- 2D/3D DNR(Digital Noise Reduction)
Compression
- Ultra 265,H.265, H.264, MJPEG
- Embedded smart algorithm
- Triple streams
- ROI (Region of Interest)
- 9:16 corridor mode
- Customized OSD
Network
- ONVIF Conformance
Structure
- Support PoE power supply
- Wide temperature range: -35°C ~ +60°C (-31°F ~ 140°F)
- Wide voltage range of ±25%
- IP67
- 3-Axis
