System

Main Processor

Embedded Processor

Network Protocol

UDP; TCP; IPv4; RTSP; SIP; P2P; RTP

OSDP Protocol

Yes

Interoperability

CGI;ONVIF

SDK and API

Yes

Basic

Product Type

Standalone

Display Screen

7" LCD

Screen Type

Capacitive Touchscreen

Screen Resolution

600 (H) × 1024 (V)

Camera

2-MP dual-lens CMOS camera

WDR

DWDR

Light Compensation

Auto IR

Voice Prompt

Yes

Casing Material

Tempered glass/PC

Function

Verification Method

Card; remote; password; fingerprint; face; combination unlock

Card Type

IC card; Desfire card (EV3,Compatible with Dahua card by default)

Period List

128 periods

Holiday Period

128 periods

Network Update

Yes

First User Unlock

Yes

Remote Verification

Yes

Restricted List/Trusted List

Yes

Wi-Fi

Yes

Wireless Standard

802.11b/g/n

Wireless Frequency Range

2.400 GHz–2.472 GHz

Max Transmission Power

≤20 [email protected] MHz

Advertisement Playing

Support graphic advertisement play

Peripheral Card Reader

Supports 1 × RS-485 card reader;
1 × Wiegand card reader

Multi-user Authentication

Yes

Real-time Monitoring

Yes

Multi-factor Authentication

Yes

Capture Function

Yes

Web Configuration

Yes

Auto Registration

Yes

Performance

Card Reading Distance

0 cm–3 cm (0"–1.18")

Face Recognition Height Range

0.9 m–2.4 m (2.95 ft–7.87 ft)

Face Recognition Distance

0.3 m–2.0 m (0.98 ft–6.56 ft)

Face Recognition Accuracy

99.9%

Face Recognition Time

0.2 s

Fingerprint Sensor Type

Capacitive

Fingerprint Verification Mode

1:N

Fingerprint Comparison Time

1.5 s

Fingerprint Recognition Time

0.5 s

Supported Codes

QR code

Code Type

Electronic code; printed code

User

User (Card) Type

General users, patrol users, blocklist users, VIP users, guest users, custom user 1, custom user 2, and other users

Capacity

User Capacity

50000

Face Image Capacity

50000

Fingerprint Capacity

10000

Card Capacity

100000

Password Capacity

50000

Record Capacity

300000

Port

RS-485

1

RS-232

1

Wiegand

1 (input or output)

USB

1 × USB 2.0 port

Network Port

1 × RJ-45 10/100 Mbps Ethernet port

Alarm Input

2 (digital quantity)

Alarm Output

1 (relay)

Alarm Linkage

Yes

Exit Button

1

Door Status Detection

1

Lock Control

1

Alarm

Anti-pass Back

Yes

Tamper Alarm

Yes

Duress Alarm

Yes

Door Sensor Timeout

Yes

Intrusion

Yes

Illegal Card Exceeding Threshold

Yes

Duress Fingerprint

Yes

General

Power Adapter

Included

Power Supply

12 VDC, 2 A

Power Consumption

≤24 W

Product Dimensions

218 mm × 118 mm × 24.2 mm (8.58" × 4.65" × 0.95") (H × W × D)

Packaging Dimensions

Carton: 299 mm × 164 mm × 72 mm (11.78" × 6.46" × 2.83") (H × W × D)
Protection box: 390 mm × 320 mm × 360 mm (15.35" × 12.60" × 14.17") (H × W × D)

Operating Temperature

–20 °C to +55 °C (–4 °F to +131 °F)

Operating Humidity

0%–90% (RH), non-condensing

Operating Altitude

0 m–1,300 m (0 ft–4,265.09 ft)

Operating Environment

Indoor

Gross Weight

0.67 kg (1.48 lb)

Accessory

Included: Wall mount bracket

Installation

Turnstile Mount; 86 case mount; wall; floor bracket mount
