The DF5450HD-DN/IR has been designed especially for applications requiring images with highest resolution in real-time at day and in the IR mode at night. Built into an IP66-rated weather-proof enclosure, the camera is designed for both indoor and for outdoor applications.

The DF5450HD-DN/IR has been designed especially for applications requiring images with highest resolution in real-time at day and in the IR mode at night. Built into an IP66-rated weather-proof enclosure, the camera is designed for both indoor and for outdoor applications..

Ultra HD resolution
The high resolution of the sensor and the sophisticated image processing enable real-time recordings with UHD resolution at a frame rate up to 25/30 fps (2160p/30) with excellent quality. Thus, the camera is ideally suited when capturing the finest detail is required in real time.

H.265 Support
The cameras are equipped with encoder technology that supports encoding of the video stream according to the H.265 standard. This allows the data rate to be reduced by up to 50% compared to H.264 with the same resolution and image quality. In conjunction with the latest Dallmeier recording systems, a significant reduction in network and storage utilization can be achieved.

Motor-driven varifocal lens with P-Iris
The camera has a motor-driven megapixel varifocal lens that is perfectly tuned to the image sensor. The adjustment of zoom, focus and iris is made conveniently using a web browser. The manual lens setting directly at the installation site of the camera is not required.

Digital Image Shift
The Digital Image Shift function allows digital fine alignment of the image section conveniently using a web browser. This ensures a quick and easy installation of the camera. The manual fine alignment of the camera directly at the installation site is not necessary.

Video Content Analysis
The integrated Video Content Analysis (VCA) detects movements and objects in the uncompressed image and analyzes them in real-time (depending on the analysis resolution) with highly developed analysis functions such as Intrusion Detection or Line Crossing. The detected events can be used to trigger the recording of a SMAVIA recording system. Together with the detected objects and the corresponding metadata, they are stored in a database. This allows the targeted search and evaluation of the recordings by SMAVIA Viewing Client with the SmartFinder function.

AI support
The cameras is equipped with encoder technology that enables Video Content Analysis supported by AI (Artificial Intelligence) functions based on neural networks in the camera. This provides a significantly more powerful object classification. After a short training phase, the system finally allows an even more targeted evaluation of the recordings and a more effective use of automatic functions such as lossless and multiple Auto-Tacking.

EdgeStorage
The camera is equipped with a RAM memory that is used by the EdgeStorage function to store the video stream in case of a network failure (e. g. Spanning Tree, Bursts). When the network is restored, the SmartBackfill function ensures fast transmission to the SMAVIA recording system. This stores the video stream with high speed and then continues to record the live stream seamlessly.

Further features

• Minimum illumination 0 lux (with IR LED On)
• Integrated homogeneous IR illumination
• Ambient light sensor and removable IR cut filter
• Automatic switching of presets for day and night
• Frame rate of 30 fps at 2160p
• Video compression H.264, H.265, MJPEG
• Functions for data protection and data security (GDPR-compliant)
• Voltage supply with PoE (Class 0)
• IP66-rated weather-proof enclosure
