Dahua IP Villa Outdoor Station with Card Reader and Keypad IK08 IP55 ***
- Keyboard villa door station
- Supplemental lighting with white light
- 2MP CMOS camera
- Mechanical button with Braille
- Aluminium alloy plate, IK08, IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
- Door release via password and Mifare card
SPECIFICATIONS
| Technical Specification | |
| Model | VTO3221E-P |
| System | |
| Main Processor | Embedded Micro Processor |
| Operation System | Embedded LINUX OS |
| Video | |
| Video Compression | H.264 |
| Image Sensor | 1/2.9” 2MP CMOS |
| Auto Gain Control | White Light |
| Lens | 2mm |
| Angle of View | H:140° V:82° |
| Day/Night | Color Image |
| Audio | |
| Audio Compression | G.711 |
| Audio Input | Omnidirectional Mic |
| Audio Output | Built-in Speaker |
| Bidirectional Talk | Support Dual-way Bidirectional talk |
| Display | |
| Screen | 2.3'' OLED |
| Operation Mode | |
| Keypad | Mechanical Button with Braille |
| Reader | Mifare Card (13.56MHz) |
| Interface | |
| Alarm In/Out | 1/1 |
| Door Control | 1 Relay Out 1 RS485 1 Feedback 1 Exit Button |
| Wiegand In | 1 |
| Network | |
| Ethernet | 10M/100Mbps |
| Network Protocol | TCP/IP |
| General | |
| Ingress Protection | IK08, IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.) |
| Tamper Switch | 1 |
| Installation | Surface & Flush |
| Material | Aluminum |
| Power | DC 12V, 2A, PoE(802.3af) |
| Power Consumption | Standby ≤2W, Work ≤7W |
| Working Temperature | ﹣40°C~+60°C |
| Relative Humidity | 20%~95%RH |
| Dimensions | 200mm×98mm×32mm |
| Weight | 1.5Kg |
| Datasheets | |
|---|---|
| Dahua IP Villa Outdoor Station with Card Reader and Keypad IK08 IP55 *** - Datasheet |
Brand: Dahua |
Code: VTO3221EP
MPN:
APN: 6939554933820 |
Supplier Code:
Brand: Dahua |
Code: VTO3221EP
MPN:
APN: 6939554933820 |
Supplier Code:
At a glance
- Keyboard villa door station
- Supplemental lighting with white light
- 2MP CMOS camera
- Mechanical button with Braille
- Aluminium alloy plate, IK08, IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
- Door release via password and Mifare card
