Camera |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor |
Panoramic network camera: 1/1.8”CMOS PTZ camera: 1/1.8”CMOS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. resolution |
Panoramic network camera: 8192×1800 PTZ camera: 1920× 1080 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System |
Progressive |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed |
Panoramic network camera: 1/3 s-1/100000 s, manual or auto adjust PTZ Camera: 1/1 s-1/300000 s, manual or auto adjust |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination |
Panoramic network camera: 0.001Lux(colour);0.0001Lux(black); PTZ camera: 0.001Lux(colour);0.0001Lux(black);0Lux(IR on) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
S/N Ratio |
Panoramic network camera:51db |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR Distance |
Panoramic network camera: — PTZ camera: ≥ 220 m (721.78t) (IR on) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR On/Off Control |
Auto/Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IR LEDs Number |
Panoramic network camera:— PTZ camera: 7 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type |
Panoramic network camera:Fixed-focal PTZ camera:Motorized vari-focal |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mount Type |
Panoramic network camera:M16 PTZ camera: Core interface |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length |
Panoramic network camera 2.8 mm PTZ camera: 5.62mm~208mm, 37x optical zoom |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture |
Panoramic network camera: F1.6 PTZ camera: F1.4 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View |
Panoramic network camera:Horizontal: 360° Vertical: 80°~85° PTZ camera:Horizontal: Horizontal: 2.61°~59.61° Vertical: 1.48°~34.92° Diagonal: 3°~66.96° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Type |
Panoramic network camera: Fixed aperture PTZ camera: Auto |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance |
Panoramic network camera: 0.2m(0.66ft) PTZ camera:0.1m~1m(0.33ft~3.28ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance |
Detect |
Observe |
Reconize |
Identify |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Panoramic network camera |
29.0m (95.14ft) |
11.6m (38.05ft) |
5.8m (19.02ft) |
2.9m (9.51ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
PTZ camera |
1930.7m (6334.31ft) |
772.27m (2533.69ft) |
386.1m (1266.73) |
193.1m (633.53ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Event |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS |
Intrusion, tripwire |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Codec |
Smart H.264+ Smart H.265+ |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Frame Rate |
Panoramic network camera:Main stream(8192×1800@1~30fps),Sub Stream(2048×452@1~30fps),Third Stream(3840×832@`~30fps) PTZ camera: Main stream(1920×1080@1~30fps),Sub Stream(704×480@1~30fps),Third Stream(1280×720@1~30fps) |
Stream Capability |
3 Streams |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
Panoramic network camera: 8192×1800;7680×1680;5760×1264;4096×900;3840×832;2560×560;2048×452 PTZ camera: 1920 × 1080; 1280 × 960; 1280 × 720; 704 × 576; 704 × 480; 352 × 288; 352 × 240 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control |
Panoramic network camera: CBR/VBR PTZ camera:CBR/VBR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate |
Panoramic network camera: H.264:112kbps ~37227Kb/S H.265:44kbps ~22546Kb/S PTZ camera: H.264:24kbps ~10752Kb/S H.265:9kbps ~6400Kb/S |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night |
Auto (ICR)/Color/B/W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
BLC |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
HLC |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR |
Panoramic network camera:DWDR PTZ camera: WDR (120 dB ) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
White Balance |
Panoramic network camera:Auto/Natural/street lamp/outdoor/manual/regional Custom PTZ camera: Auto/indoor/outdoor/tracking/manual/sodium lamp/natural/street lamp |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gain Control |
Auto/Manual |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction |
3D NR |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection |
Disable/Enable |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest (RoI) |
Yes (4 areas) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Image stabilization(EIS) |
Panoramic network camera: — PTZ camera: Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart IR |
Panoramic network camera: — PTZ camera: Yes (Adjusted by user.) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Defog |
Panoramic network camera: — PTZ camera: Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Rotation |
0°/180°(PTZ camera) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy masking |
4 areas(Panoramic network camera);24 areas(PTZ camera) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression |
G.711Mu;G.711A;G.726 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
RJ-45 (10/100/1000 Base-T) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocol |
IPv4;IPv6;HTTP;HTTPS;TCP; UDP;ARP;RTP ; RTSP;RTCP; RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS; QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;SAMBA;PPPoE;802.1x;SNMP |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability |
ONVIF (Profile S/Profile G); CGI; Milestone;Genetec |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
User/Host |
20 (Total bandwidth: 1000 M) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Edge Storage |
FTP;SFTP; Micro SD card (support max. 256 G); Dahua Cloud; NAS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Browser |
Chrome 42 Firefox 52 IE7;IE8;IE9;IE11 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software |
EVS5XX,EVS7XX,NVR5X-I,NVR4X-4KS2 ,M70,IVSS7X ,DSS Pro&DSS express |
Certification |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification |
CE-LVD: EN60950-1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PTZ Dome |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pan Range |
Pan: 0° to 360° endless |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Manual Control Speed |
Pan: 240°/s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Remote Lens Reset |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Preset |
300 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Tour |
8 Tour (up to 32 preset per tour) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pattern |
5 patterns |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scan |
5 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power-off Memory |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Idle Motion |
Preset/Pattern/Tour/Scan |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Time Task |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Three-dimensional Positioning |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PTZ Limit |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Position Display |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Information Display |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Time Display |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Optical Fiber |
FC,single mode, single fiber |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input |
2 channels (terminal) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output |
2 channels (terminal) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input |
7 channels in: 5mA 3V–5V DC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output |
3 channels out: 1,000mA 30V DC/500mA 50V DC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
DC36V |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
MAX:74W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature |
-40°C to +70°C(-104°F to +158°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity |
≤95% |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature |
-40°C to +70°C (-104°F to +158°F)/Less than 95% RH |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ingress Protection |
IP66;IK10(optional) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Enclosure |
Metal + Plastic |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions |
Φ383 mm × 389.8 mm (Φ1256.56 ft × 1279.8 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
14.7 kg (32.40 lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
19.8 kg (43.65 lb) |
