Performance |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Layer |
Layer 2 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Managed |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Switching Capacity |
8.8 Gbps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packet Forwarding Rate |
5.36 Mpps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packet Buffer Memory |
2.75 Mbit |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
MAC Table Size |
4K |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Communication Standard |
IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE 802.3ab; IEEE 802.3z |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Hardware Feature |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Standard Power Supply |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ethernet Port |
16 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Optical Port |
2 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ethernet Port Rate |
100 Mbps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Optical Port Rate |
1 Gbps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Number of Bussiness Card Slots |
Port 1-16: 16 × RJ-45 10 M/100 M (PoE) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Debugging |
Console × 1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
100V–240V AC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature |
–10 °C to +55 ° (14 °F to 131 °F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity |
10% RH–90% RH |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
Idling: 10W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Standard |
IEEE802.3af/ IEEE802.3at/ Hi-PoE/IEEE802.3bt |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Budget |
Port 1-2 ≤ 90W, Port 3-16≤ 30W, total ≤ 190W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Pin Assignment |
1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Management |
Power consumption management |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Long Distance PoE Transmission |
250 m long-distance power supply |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Function |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Spanning Tree Protocol |
IEEE 802.1d (STP); 802.1w (RSTP) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
VLAN |
IEEE802.1q Standard VLAN |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Flow Control |
Support IEEE 802.3x (full duplex flow control) and back pressure flow control (half duplex) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Link Aggregation |
Static; LACP |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port Mirroring |
One-to-one; multiple-to-one |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Multicast |
GMP snooping based on port |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DHCP |
DHCP client |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Security |
Hardware supports IP and MAC binding based on port, MAC filtering based on port, and IEEE802.1x port authentication |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
QoS |
High and low priority |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ESD |
Air discharge: 8kV |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Thunder-proof |
Common mode: 4kV |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions |
440 mm × 300 mm × 44 mm (17.32" × 11.81" × 1.73") (L × W × H) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packaging Dimensions |
Packing box: 527 mm × 412 mm × 110 mm (20.75" × 16.22" × 4.33") (L × W × H) |
