Display |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Model |
LDV49-SAI200 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen Size |
49'' |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Aspect Ratio |
9:16 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution |
1080×1920 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display Colors |
16.7M (8 bits) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Brightness |
400nits |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Contrast Ratio |
1200:1 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Viewing Angle(H×V) |
178°/178° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display Mode |
Portrait |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Response Time |
8ms |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lifespan |
30,000h |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Connectivity |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Input |
RJ45×1, USB2.0×2, SD×1, HDMI(customized) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Output |
N/A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
External Control |
RS232 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wi-Fi |
Yes |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Speaker |
2W×2 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Signage Platform |
Media Publish System |
Power & Environmental Conditions |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply |
AC100-240V (+/- 10%), 50/60Hz |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Type |
Internal |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Consumption(Typical) |
70W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Consumption(Standby) |
Less than 0.5W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature |
-10℃~+55℃(14℉~131℉) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity |
10%~90% |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mechanical Specification |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions (With Pedestal) |
2013.5×721.7×63.6mm (79.3"×28.4"×2.5") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Package |
Screen |
2043×902×299mm(80.4"×35.5"×11.8") |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pedestal |
902×683×354mm(35.5"×26.9"×13.9") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
Screen |
77.2kg(170.2lb) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pedestal |
20.5kg (45.2lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Accessory |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Included in Box |
Power cord, Wi-Fi antenna, user manual, remote control |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pedestal |
LDV49-DZ, hex bolt, screws(M8*30) |
Internal Player |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Processor |
Cortex-A7 1.5GHz Quad Core CPU |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM |
1GB(2G customized) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage |
8GB(16G customized) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Material Type |
Audio, video, image, time, weather, countdown, txt, web page, stream media, pdf |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio/Video Encoding Format |
Mp4, avi, mov, asf, wmv, rm, rmvb, mkv, jpg, jpeg, gif, bmp, png, mp3, wma, wav |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System |
Android 4.4(Android 5.1 customized) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Decoding Capacity |
1ch@4K or 3ch@1080P |
