Dahua IP 6MP 1.7mm IP67 Panoramic Fisheye Camera** IPCEBW8630 | C.R. Kennedy

Dahua IP 6MP 1.7mm IP67 Panoramic Fisheye Camera**

Dahua IP 6MP 1.7mm IP67 Panoramic Fisheye Camera**

  IN STOCK
PRODUCT ENQUIRY
  • 1/1.8” 6Megapixel progressive scan STARVIS™ CMOS
  • H.265/H.264 triple-stream encoding
  • Max 25/30fps@6M(3072x2048)
  • Multiple dewarped Mode
  • Day/Night(ICR), 3DNR, AWB, AGC, BLC
  • Smart detection
  • Intelligent Function
  • Max. IR LEDs length 10m
  • Micro SD memory, IP67, IK10, PoE



Brand: Dahua   |    Code: IPCEBW8630
APN: CRK9901056   |    Supplier Code: IPCEBW8630

True Day/Night

A day/night mechanical IR cut filter makes this camera ideal for applications with fluctuating lighting conditions, delivering color images during the day and automatically switching to monochrome as the scene darkens.

Panoramic

Panoramic cameras provide 180 °, 360 ° full range of video scene, bringing people a new sense of real live and interactive experience. Dahua provides two kinds of panoramic camera, single lens fisheye camera and multi-lens camera, both of them can offer 180-degree & 360-degree panoramic image. Through working together with PTZ camera which offer whole scene and region details at same time. It provided new surveillance experience to end user and improved the surveillance quality.

Business intelligent analysis (Heatmap)

Dahua fisheye camera also supports advanced intelligent feature like heat map besides basic IVS functions. The heatmap function can be applied to business intelligence and bring extra values to customers. The heat map function based on a moving object in time of space movement for analysis, find the most active area and output the report, which is to provide valuable data support for commercial applications. Smart IR With IR illumination, detailed images can be captured in low light or total darkness. The camera's Smart IR technology adjusts the intensity of camera's infrared LEDs to compensate the distance of an object. Smart IR technology prevents IR LEDs from whitening out images as they come closer to the camera. The camera's integrated infrared illumination provides high performance in extreme low-light environments up to 10m (33ft).

HEVC(H.265)

H.265 ITU-T VCEG is a new video coding standard. H.265 Following standard developed around the existing video coding standard H.264 , some retain the original technology , while some of the relevant technology to improve the new technology uses advanced technology to improve the relationship between the code stream , encoding quality , and the delay between algorithm complexity , optimize settings specific contents include : Improve compression efficiency , improve the robustness and error recovery capabilities, real-time to reduce the delay, reduce channel acquisition time and a random access delay , reduce complexity , etc

Protection (IP67, IK10, wide voltage)

Supporting ±25% input voltage tolerance, this camera suits even the most unstable conditions for outdoor applications. Its 6KV lightning rating provides effective protection for both the camera and its structure against lightning.IP67 is supported by the camera, which makes it suitable for both indoor and outdoor environments. IK10 compliance enables the camera to sustain the equivalent of 55 kg (120lbs) force.

Dahua fisheye camera is an expert at panoramic surveillance with low-profile design. With a fisheye lens, the camera can provide a high quality 180°or 360°panoramic views without blind spots, making it ideal for wide and open areas, such as airports, shopping malls, banks, hotels, stores, offices and more. The camera can offer different views including 360°overview and dewarped views such as panorama view, double views and quad views.
Camera
Image Sensor 1/1.8” 6Megapixel progressive scan CMOS
Effective Pixels 3072(H)x2048(V)
RAM/ROM 1024MB/128MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual, 1/3~1/100000s
Minimum Illumination 0.002Lux/F2.0( Color,1/3s,30IRE)
0.02Lux/F2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
S/N Ratio More than 50dB
IR Distance Distance up to 10m(33ft)
IR On/Off Control Auto/ Manual
IR LEDs 3
Lens
Lens Type Fixed
Mount Type Board-in
Focal Length 1.7mm
Max. Aperture F2.0
Angle of View H: 180˚, V:180˚
Optical Zoom N/A
Focus Control Fixed
Close Focus Distance N/A
DORI Distance Detect: 28m
Observe: 11m
Recognize: 6m
Identify 3m
Pan/Tilt/Rotation
Pan/Tilt/Rotation Range N/A
Intelligence
IVS Tripwire, Intrusion
Advanced Intelligent Functions Heat Map
Video
Compression H.265/H.264
Streaming Capability 3 Streams
Resolution 6M(3072×2048)/ 4M(2048x2048)/ 3M(2048x1536)/ UXGA(1600x1200)/ 1.3M(1280x960)/ D1(704×576/704×480)/ CIF(352×288/352×240)
Frame Rate Main Stream: 6M(1~25/30fps)
Sub Stream: D1(1 ~ 25/30fps)
Third Stream: 1.3M(1 ~ 25/30fps)
Bit Rate Control CBR/VBR
Bit Rate H.265: 3Kbps~ 9984Kbps
H.264: 8Kbps~ 16384Kbps
Day/Night Auto(ICR) / Color / B/W
BLC Mode BLC / HLC / DWDR
White Balance Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detetion Off / On (4 Zone, Rectangle)
Region of Interest Off / On (4 Zone)
Electronic Image Stabilization(EIS) N/A
Smart IR Support
Defog Support
Digital Zoom 16x
Flip N/A
Mirror N/A
Privacy Masking Off / On (4 Area, Rectangle)
Audio
Compression G.711a/G.711Mu/AAC/ G.726
Network
Ethernet RJ-45 (100/1000Base-T)
Protocol HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP;Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP
Interoperability ONVIF, PSIA, CGI
Streaming Method Unicast / Multicast
Max. User Access 10 Users/20 Users
Edge Storage NAS
Local PC for instant recording
Micro SD card 128GB
Web Viewer IE, Chrome, Firefox, Safari
Management Software Smart PSS, DSS, Easy4ip
Smart Phone IOS, Android
Certifications
Certifications CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B
Interface
Video Interface N/A
Audio Interface 1/1 channel In/Out, 1 Built-in Mic
RS485 N/A
Alarm 2 channel In: 5mA 5VDC
2 channel Out: 1A 30VDC / 0.5A 50VAC
Electrical
Power Supply DC12V, PoE (802.3af)(Class 0)
Power Consumption <12W
Environmental
Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Strorage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection IP67
Vandal Resistance IK10
Construction
Casing Metal
Dimensions Φ149.8mm×50.7mm(Φ5.9”×2”)
Net Weight 0.58kg(1.28lb)
Gross Weight 1.0kg(2.2lb)
