For designers, photographers, or prepress professionals who rely on accurate color throughout a digital workflow, the i1Publish Pro 3 Plus is the must-have solution to profile and calibrate cameras, monitors, projectors, scanners, and both RGB and CMYK+ printers. Get the most color accurate displays, prints and proofs, with repeatable results every time.
Accommodating a broad range of proficiencies and expertise, i1Publish Pro 3 Plus provides complete power and control to create the highest quality ICC profiles. Choose between a basic, wizard-driven interface, or an advanced user-driven interface to create high quality, precise, custom color profiles.
Benefits:
Aperture
Measurement aperture: 8 mm (0.31”) diameter (effective measurement aperture during scanning is depending on the patch size and measurement speed)
Available Disk Space
2GB
Calibration
Manual on external ceramic white reference (included)
Communication Interface
USB 1.1
Connectivity
Powered USB port
Dimensions (length, width, height)
i1Pro device: 162 mm x 69 mm x 64 mm (6.4” x 2.7” x 2.5”)
Display Resolution
1024x768 pixels or higher
Experience Level
Intermediate to Advanced
Humidity
30 to 85% RH (non-condensing)
Illumination Spot Size
12 mm (0.47”)
Inter-Instrument Agreement
0.4 ∆E00* average, 1.0 ∆E00* max. (deviation from X-Rite manufacturing standard at a temperature of 23ºC (73.4ºF) on 12 BCRA tiles (D50, 2º))
Internet Connection
Required for software install, download and automatic update
Languages Supported
Chinese (Simplified), English, French, German, Italian, Japanese, Korean, Portuguese, Spanish
Light Source
i1Pro3 Plus LED Illumination (including UV)
Macintosh
MacOS X 10.11x, 10.12x or 10.13x (with latest upgrades installed)
Measurement Conditions
Measurement Frequency in Scanning Mode
400 measurements per second
Measurement Geometry
45°:0° ring illumination optics, ISO 13655:2017
Measurement Spot
8mm (0.315”)
Media Thickness
1mm or less
Memory
2GB Minimum
Number of Displays Supported per Workstation
Up to 4
Operating Temperature Range
10°C to 35°C 50°F to 95°F
Patch Size
Minimal Patch Size in Scanning Mode: 16 x 16 mm (0.63” x 0.63”) (Width x Height) with sensor ruler 20 x 16 mm (0.79” x 0.63”) (Width x Height) without sensor ruler
Photometric Range
10nm; Sampling interval 3.5nm
Processor
MAC: Intel® Core 2 Duo CPU or better; WINDOWS: Intel® Core 2 Duo or AMD Athlon™ XP or better
Scan Length
Maximum 515mm (20.28")
Scanner Target Support
Yes
Scanning Capability
Security
User must have Administrator rights to install and uninstall the application
Short Term Repeatability - White
Reflectance: 0.1 ∆E94* (D50,2°, mean of 10 measurements every 3 seconds on white)
Software Development Kit
Available for OEM customers
Spectral Analyzer
i1® technology with built-in wavelengths check; Holographic diffraction grating with 128-pixel diode array
Spectral Range
380 - 730 nm
Spectral Reporting
380 ... 730 nm in 10 nm steps
Storage Temperature Range
-20° to 50°C -4° to 122°F
Supported Profile Format
ICC version 2, version 4.3, & iccMax
Unit Color
Black/Silver
User Experience
Choose between a ‘basic’, wizard-driven interface or an ‘advanced’, user-driven interface for highest level professional results
Video Card
MAC: Latest drivers for video card installed
WINDOWS: Latest drivers for video card installed, dual display support requires either 2 video cards or a dual head video card that supports dual video LUTs being loaded
Warranty
Twelve (12) months from the date of sale, unless different local regulations apply. Product registration is required to receive X-Rite technical support during the warranty period. Registration can occur directly through the software, on our website, or via phone. Users are encouraged to register their product within the first 30 days of use.
Weight
i1Pro device: 285 g (10.1 oz)
Windows
Windows 7, 8, 8.1, 10 (with latest Service Pack installed)
