DC5506 | DC5509 | |
Video Input | ||
DVI-D input | 1-ch, 1024x768(XGA)@60HZ、1280x720(720P)@60HZ、1280x1024(SXGA)@60HZ、1440x900(WSXGA)@60HZ、1600x1200(UXGA)@60HZ、1920X1080(1080P)@60HZ |
|
Video Output | ||
DVI-D output | 6-ch 1024x768(XGA)@60HZ、1280x720(720P)@60HZ、1280x1024(SXGA)@60HZ、1440x900(WSXGA)@60HZ、1600x1200(UXGA)@60HZ、1920X1080(1080P)@60HZ |
9-ch 1024x768(XGA)@60HZ、1280x720(720P)@60HZ、1280x1024(SXGA)@60HZ、1440x900(WSXGA)@60HZ、1600x1200(UXGA)@60HZ、1920X1080(1080P)@60HZ |
Video Decoding | ||
Video Stream Format | H.265/H.264 | |
Decoding Capability | 6x4K@30, 24x1080P@30, 54x720P@30, 96×D1 | 9x4K@30, 36x1080P@30, 81x720P@30, 144×D1 |
Display split | 1/2/3/4/6/7/9/16 | |
External Interface | ||
Audio Input | 1-ch (Reservation) | |
Audio Output | 1-ch (Reservation) | |
Alarm Input | 6 (Reservation) | |
Alarm Output | 3 (Reservation)) | |
Serial Interface | 1 RS-232, 1 RS485 | |
Network Interface | 1 RJ-45 , 10M/100M/1000M adaptive Ethernet Interfaces | |
USB Interface | 1, USB 3.0 | |
WIFI | 1 (Reservation) | |
General | ||
Power Supply | 100~240 VAC | |
Consumption | <54 W | |
Working Temperature | -10°C ~ + 55°C | |
Working Humidity | 5% ~ 95% (No-condensing) | |
Weight | 3.5 Kg | |
Dimensions ( H x D x W ) | 44mm(H)×440mm(V)×339mm(D) |
