The standard functions that allow you to zoom in and view the subject freely, such as the camera head and arm movable mechanism, the zoom dial and one-push autofocus that can be operated with one hand, were popular in the previous model. It has evolved as a hybrid model that can handle digital content and realize analog and digital elements in a single unit.
Programming application "Scottie Go!" Is standard equipment. In addition, by installing Android1 OS, various class support applications are installed2 to realize “independent, interactive and deep learning” that the new course of study aims such as programming education, English pronunciation, and distance learning. It can be used for various lesson scenes.If you download other applications, you can also play presentations and video files just like a computer.
It is equipped with a function that allows you to draw with an electronic pen on top of the image projected by the camera which easy to present and explain using the real thing. The drawn image can be saved not only writing by combining with accessories such as the unit type electronic blackboard "CRB-2", but also operate the document camera. It is also possible to present, write and save on the electronic blackboard "xSync Board"3.
Miracast4 function is installed, no cable connection is required for Miracastcompatible monitors.
If you read the QR code written in textbooks with L-12W, you can connect Internet and display through online content on a large presentation device. Hybrid usage from analog to digital.
It is equipped with a wired LAN port and wireless LAN (Wi-Fi), it can be used according to the school environment. You can also access the school LAN server to play and save files, and use the built-in web browser to browse documents and videos on the Internet.
The L-12W has an internal memory for saving images and movies, as well as an SD card and USB memory. You can also play back image data saved in memory and save class records.
Detects print paper and textbooks placed in the imaging area under the camera, converts them straight, and automatically closes up (digital zoom) to display the optimal image. Regardless of where you put it5, press and hold the main unit freeze button to start correction and display it at the optimal position.
It is equipped with a 12x optical zoom that displays small and large images clearly, a 16x higher definition digital zoom (including a 1.7x sensor zoom), image quality is reduced even when enlarged. Smooth motion is reproduced with high definition and high image quality of maximum Full HD (1920 × 1080p) on a frame rate of 30fps. A3 Shoots up to full horizontal size.
The L-12W includes accessories to prevent accidental disconnection of the HDMI cable. In addition, a remote-control storage location is provided on the main unit, making it easier to use.
HDMI and RGB input terminals are also provided on the main unit. You can switch between the document camera screen and computer screen with a single touch.
DC5V (AC adapter AC100- 240V/ 20W)
1 / 3.2-inch CMOS 8 million pixels
Effective pixel count
3,264x 1,836 (16:9)
2,992x 2,244 (4:3)
F= 3.46-41.5 12X Zoom lens F=3.2-3.6
Optical 12X Digital 16X
4:3: Max 430mm x 320mm, Min 50.7mmx 38.0mm 16:9 Max 470mmx 260mm, Min 55.2mmx 31.0mm
Focus adjustable range
50mm to ∞ (wide)
200mm to ∞ (tele)
Automatic (one push)
HDMI and RGB: 1080p, 720p, UXGA, XGA
USB: 1920x1080, 1280x720, 1600x1200, 800x600, 640x480
0°/ 90 ° / 180 °/ 270°
Spilt screen display
2 screen/ 4 screen (camera image, still image on memory)
Body/ External (RGBx1, HDMIx1)
USB camera function
Available (USB Video Class compatible)
RGB output Mini D sub 15P connector female x1
HDMI output terminal x1
Line output terminal Φ3.5mm stereo mini jack x1
RGB input Mini D sub 15P connector female x1
HDMI input terminal x1
Microphone input terminal Φ3.5mm stereo mini jack x1
USB2.0 host type B receptacle x1
USB2.0 host type A receptacle x2
SD card slot x1
LAN x1 10BASE-T, 100BASE -T
Wi-Fix1 IEEE 802.11 a/b/g/n 2.4GHz/ 5GHz
Width: 349mm Depth: 377mm Height: 432mm (set-up) Width: 195mm Depth: 294mm Height: 475mm (fold)
Approximately 3.0 kg. (main unit only)
