Tokina Cinema 11-16mm T3 DX Lens for Micro Four Thirds Mount ** 1116CINEDXMFT | C.R. Kennedy

Tokina Cinema 11-16mm T3 DX Lens for Micro Four Thirds Mount **

Tokina Cinema 11-16mm T3 DX Lens for Micro Four Thirds Mount **

$2,012.99
  NO STOCK
  NO STOCK
PRODUCT ENQUIRY

The Tokina Cinema 11-16mm T3.0 with Micro Four Thirds Mount is a wide-angle zoom lens for APS-C or Super-35 sized sensors and features a Canon EF lens mount.

Brand: Tokina   |    Code: 1116CINEDXMFT
APN: 4968808220036   |    Supplier Code: 1116CINEDXMFT

The Tokina Cinema 11-16mm T3.0 with Micro Four Thirds Mount is a wide-angle zoom lens for APS-C or Super-35 sized sensors and features a Canon EF lens mount. The lens uses the same distortion-free design and optical performance of Tokina's 11-16mm f/2.8mm DSLR lens, but puts it into an all-metal housing optimized for video and digital cinema use. The housing provides manual focus control with an easy-to-read distance scale and a de-clicked aperture ring for smooth iris pulls. The focus, aperture, and zoom rings all have standard 0.8 pitch gears for use with follow focus systems.

The Tokina 11-16mm T3.0 utilizes two super-low dispersion and two aspherical lens elements to produce images with high contrast and sharpness, while multi-layer coating help minimize flare and ghosting. A bayonet mount, petal-type lens hood is included.

  • Ultra-wide angle T3.0 zoom lens
  • Covers APS-C and Super-35 sized sensors
  • 4K image sharpness
  • Rugged all-metal lens housing
  • 0.8 Pitch geared focus, aperture, and zoom rings
  • 9-Blade aperture diaphragm
  • 77mm Filter diameter
  • Min. focus distance of 13.78"

Focal Length

11 - 16mm

Lens Mount

Micro Four Thirds

Format

Super 35/APS-C

Maximum T-Stop

T3.0

Maximum F-Stop

f/2.8

Minimum T-Stop

T22

Diagonal Angle of View

Super 35: 104 - 84°

Minimum Focus Distance from Image Plane

13.78" / 35 cm

Elements/Groups

13 / 11

Iris Blades

9

Gear MOD & Pitch

Focus: 0.8 MOD / 32 Pitch
Iris: 0.8 MOD / 32 Pitch
Zoom: 0.8 MOD / 32 Pitch

Filter Thread

77 mm

Zoom Ratio

1.45x

Maximum Magnification Ratio

1:4.94

Dimensions (W x H)

3.27 x 3.27" / 83.1 x 83.1 mm

Length

4.8" / 120.7 mm

Weight

1.72 lb / 0.78 kg

This product has yet to be reviewed

To be the first to review this product simply fill out the form to the left and let us know how you feel about this product!


To estimate the freight on this item simply enter the destination postcode and the desired quantity and click the "estimate" button.

OVERVIEW

The Tokina Cinema 11-16mm T3.0 with Micro Four Thirds Mount is a wide-angle zoom lens for APS-C or Super-35 sized sensors and features a Canon EF lens mount. The lens uses the same distortion-free design and optical performance of Tokina's 11-16mm f/2.8mm DSLR lens, but puts it into an all-metal housing optimized for video and digital cinema use. The housing provides manual focus control with an easy-to-read distance scale and a de-clicked aperture ring for smooth iris pulls. The focus, aperture, and zoom rings all have standard 0.8 pitch gears for use with follow focus systems.

The Tokina 11-16mm T3.0 utilizes two super-low dispersion and two aspherical lens elements to produce images with high contrast and sharpness, while multi-layer coating help minimize flare and ghosting. A bayonet mount, petal-type lens hood is included.

  • Ultra-wide angle T3.0 zoom lens
  • Covers APS-C and Super-35 sized sensors
  • 4K image sharpness
  • Rugged all-metal lens housing
  • 0.8 Pitch geared focus, aperture, and zoom rings
  • 9-Blade aperture diaphragm
  • 77mm Filter diameter
  • Min. focus distance of 13.78"

SPECIFICATIONS

Focal Length

11 - 16mm

Lens Mount

Micro Four Thirds

Format

Super 35/APS-C

Maximum T-Stop

T3.0

Maximum F-Stop

f/2.8

Minimum T-Stop

T22

Diagonal Angle of View

Super 35: 104 - 84°

Minimum Focus Distance from Image Plane

13.78" / 35 cm

Elements/Groups

13 / 11

Iris Blades

9

Gear MOD & Pitch

Focus: 0.8 MOD / 32 Pitch
Iris: 0.8 MOD / 32 Pitch
Zoom: 0.8 MOD / 32 Pitch

Filter Thread

77 mm

Zoom Ratio

1.45x

Maximum Magnification Ratio

1:4.94

Dimensions (W x H)

3.27 x 3.27" / 83.1 x 83.1 mm

Length

4.8" / 120.7 mm

Weight

1.72 lb / 0.78 kg
