Tokina atx-i 11-20mm f/2.8 CF Lens

Loading
  • Tokina atx-i 11-20mm f/2.8 CF Lens

Product options:

  • Aperture Range: f/2.8 to f/22
  • Three Aspherical Elements
  • Three Low Dispersion Elements
  • Anti-Reflective Multi-Layer Lens Coating
  • SD-M AF Motor, Internal Focusing
  • One-Touch Focus Clutch Mechanism
  • Water-Repellent Top Coating
  • 9-Blade Diaphragm
  • About ATX-i Series

    Leaving the honorable AT-X abbreviation, the letter "i" was newly added. "i" stands for "interactive", implying mutual communication between photographer and the lens. This is our believe that this series will provide a tight bond between photographer and the lens in order to capture in the image that the photographer sees around.

    Exterior, specifications and performance of Tokina's popular and well acknowledged so far AT-X PRO lenses are reconsidered with the contemporary cameras in mind and launched under atx-i brand.

    Product Overview

    The Tokina atx-i 11-20mm F2.8 CF is designed as an ultra wide angle zoom lens for APS-C sensor DLSR cameras. It is the only f/2.8 fast ultra wide angle zoom lens for APS-C sized DSLR cameras on the current market*.

    Focal length 11-20mm that covers equivalent angle of wide prime 18mm, 21mm, 24mm, 28mm lenses makes this lens attractive to be chosen after standard zoom lens or initially possessed wide angle zoom kit lens.

    A constant maximum aperture of f/2.8 throughout the entire zoom range is realized to achieve great results in low light conditions, for depth of field control and easy manual shooting, while maintaining a reasonable size and weight.

    * At present time April, 2020

    Optical Performance

    To achieve an exceptional optical performance required for ultra wide angle zoom lens 3 aspherical glass elements and 3 Super-Low Dispersion glass elements were used in order to minimize distortion, manage spherical aberration and astigmatism while achieving excellent edge-to edge resolution and high contrast through the entire image.

    Anti-reflective multi-layer coating improves light transmission and minimizes reflections while newly applied water-repellent coating makes wiping and cleaning the surface of the front glass element easier.

    Anti-reflective multi-layer coating improves light transmission and minimizes reflections while water-repellent coating makes wiping and cleaning the surface of the front glass element easier.



    Built Quality & Exterior Design

    Devoted to its traditions, Tokina incorporated a lot of metal parts inside the lens for a reassuring built quality and long time utilization in different shooting conditions.

    The sophisticated exterior design is specifically developed to match the design of contemporary DSLR cameras.



    Mechanics & Electronics

    The Tokina atx-i 11-20mm F2.8 CF for Nikon F mount incorporates internal Silent-Drive focusing Motor (SD-M) in combination with precise GMR sensor to allow the lens to AF accurately and fast.

    One-touch focus Clutch mechanism allows to switch between autofocus and manual focus easy.

    Highly valued One-touch focus Clutch mechanism allows to switch between autofocus and manual focus easy.

    The overall length of the Tokina atx-i 11-20mm F2.8 CF does not change when focusing and zooming thanks to internal type of the focus. Zooming mechanism inside the barrel allows using C-PL filters attached.

    Focal Length

    Nikon : 11 to 20mm (35mm Equivalent Focal Length: 16.5 to 30mm)
    Canon : 11 to 20mm (35mm Equivalent Focal Length: 17.6 to 32mm)

    Maximum Aperture

    f/2.8

    Minimum Aperture

    f/22

    Lens Mount

    Nikon F
    Canon EF

    Format Compatibility

    APS-C

    Angle of View

    104° to 72°

    Minimum Focus Distance

    28 cm

    Maximum Magnification

    0.12x

    Optical Design

    14 Elements in 12 Groups

    Diaphragm Blades

    9

    Focus Type

    Autofocus

    Image Stabilization

    No

    Filter Size

    82 mm (Front)

    Dimensions (ø x L)

    89 x 94.3 mm

    Weight

    570 g

    Product Manuals
    Tokina atx-i 11-20mm f/2.8 CF Lens - Product Manual

  • Tokina atx-i 11-20mm f/2.8 CF Lens
  • Front and Rear Lens Caps
  • Tokina 82mm Bayonet Lens Hood for AT-X AF 175 PRO FX 17-35mm f/4
  • Brand: Tokina | Code: 12X1562U01
